Page - 22/43 AEXZP0BB - ECO SMART DISPLAY - User Manual
7.4 Description of programmable functions
MENU SET MODEL
1) CONNECT TO
Using CANBUS link, every module connected to can net can act as the
“access node” to the canbus net for the external world.
For example the ZAPI hand console (or the PC-Win console) can be
physically connected to one module and, by the canbus, virtually connected
to any other module of the net.
This parameter is used to select the module to which the user wishes to be
connected.
Following the numbers associated to each module in Zapi canbus system are
showed.
Number associated in
canbus net
MODULE
01 SICOS
02 TRACTION
03 TRACTION MASTER
04 TRACTION SLAVE
05 PUMP
06 EPS-AC
09 MHYRIO/HVC
16 ECO SMART DISPLAY
MENU SET OPTIONS
1) OPERATOR PASSW.
It enables or disables password request at key on.
- ON: Starting password requested
- OFF: Starting password not requested
2) CONSOLE ENABLE
It makes available or not console menu.
- ON: Zapi Console menu is available
- OFF: Zapi Console menu is not available
3) PERFORMANCE TYPE
It sets the traction mode.
- LEVEL 0: it sets traction mode #1
- LEVEL 1: it sets traction mode #2
- LEVEL 2: it sets traction mode #3
- LEVEL 3: it sets traction mode #4
4) PERFORM. ENABLE
It can enable or disable operator changing truck performances using button
W.
- ON: Enabled operator
- OFF: Not enabled operator
5) SPEED UNIT
It sets the speed unit.
- OPTION #1: the speed unit is km/h
- OPTION #2: the speed unit is mph
6) HOUR COUNTER
It sets the hour counter displayed.
