Page 12/60 H2B USER'S MANUAL - 550145G
3 INSTALLATION
Install the chopper with the base-plate on a flat metallic surface that is clean and unpainted.
Apply a light layer of thermo-conductive grease between the two surfaces to permit better
heat dissipation.
Despite the protection provided against external agents, the continuous attack of corrosive
substances may cause the connector contacts to oxidise, thus jeopardising good function-
ing. Keep this in mind when choosing the installation position on the vehicle.
Use the special holes on the base-plate for fastening the chopper.
Make sure that the wiring of the cable terminals and connectors is carried out correctly.
Fit anti-jamming filters on the horn, solenoid valves, and contactors not connected to the
chopper such as those for activating the pump motor or hydrodrive motor, if the latter is not
handled by the chopper itself.
3.1 CONNECTION CABLES
For the auxiliary circuits, use cables of 0.5mm² section.
For power connections to the motor and to the battery, use cables having sections of
35 - 50mm².
For the best chopper performance, the cables to the battery should be run side by side and
be as short as possible.
3.2 CONTACTORS
Choose the type of contactors on the basis of the maximum operating current of the motor
and the specific chopper configuration.
- The current absorbed by the coil must not be greater than 3 amp.
- The coil suppressors are inside the chopper; do not use contactors with arc suppres-
sors.
- For contactors with magnetic suppressors, make sure you respect the polarity indicated
on the cap.
3.3 FUSES
- Use a 10 amp fuse for auxiliary circuit protection.
- For protecting the power unit, see the diagrams.
The value shown is the maximum allowable. For special applications or requirements
this value can be reduced.
For safety reasons, we recommend that you use protected fuses in order to prevent the
spread of fused particles in the event of blowout.
