Zero ARB Service Manual

Revision Date – 15/07/2020 page 41
9.7 Compressor base plate – Replace
Remove the front cover as described in Section
9.3.
It may not be necessary to remove all circuit
boards as described in Section 9.3.
Remove the bolts securing the compressor to the
base plate. To do this, you will need to hold the
top securing nuts with a spanner.
It is recommended to the prop the compressor
while doing this as the compressor is quite heavy
and will damage other components if moved.
With screw driver, remove feet secured to the
base.
Remove the AC rectifier retaining screws.
Remove the condenser retaining screws.
Depending on the fridge model, the condenser
may be secured with screws beneath the base, or
above the base.
