Zetor Proxima 90 User Manual

122
ADDITIONAL WEIGHTS
P11NE551 P11NE551 E553
WEIGHTS IN FRONT OF THE
BONNET MASK
Weights in front of the mask
Combination of
weights (pcs)
Weights
(kg)
4+1 4x50 + 66 266
8+1 8x50 + 66 466
WEIGHTS OF THE FRONT THREE-
POINT HITCH
Weights of the front three-point hitch
Combination of
weights (pcs)
Weights
(kg)
10 10x28 280
WEIGHTS OF REAR WHEELS
Combination of
weights (pcs)
Weights
(kg)
2+2 2x16 + 2x30 90
2+4 2x16 + 4x30 150
2+8 2x16 + 8x30 270
A - Mounting of weights for rear wheel
treads 1,350 to 1,500mm
B - Mounting of weights for rear wheel
treads 1,575 to 1,800mm

Zetor Proxima 90 Specifications

General

Engine Power	87 hp
Fuel Tank Capacity	90 l
Hydraulic System	Open center
Engine Cylinders	4
Fuel Type	Diesel
Displacement	4.156 L
Hydraulic pump flow	50 L/min
PTO Speed	540/1000 rpm
Transmission	12F/12R
Maximum Lift Capacity	4, 200 kg
Engine	Zetor
Max. lifting force	4, 200 kg
