Transmission oil
Check the level using the dipstick at the top of the transaxle.
If the level is low, add more oil through the filler.
Caution: Always ensure that you use the correct oil for topping up or oil changes.
Fuel
1 - Maximum Level
2 - Minimum Level
U18N061
1 - Oil dipstick
2 - Filler
U18N062
1 - Drain plug
U18N063
1 - Fuel Tank
Look at the fuel gauge to check the fuel level and refill if it
is too low.
It is good to refill the tank after using the tractor to avoid
condensation of water in the tank.
U18N064
