3. Technical Parameters
Figure
Interface:
485: Terminal
Power Supply:
terminal
Size:
L x W x H =8.7cm×3.6cm×5.9cm
Communicate Interface
Ethernet:
RJ45 interface, 2KV surge protection
Serial
RS485×1: RXD, TXD, GND
Serial Parameters
Baud rate:
1200~115200bps
Parity:
None, odd check,
even check, mark,
space
Data bits:
5～9
Flow control:
None
Software
protocol:
ETHERNET, IP, TCP, UDP, HTTP, ARP, ICMP, DHCP, DNS
Setting method :
ZLVirCom, WEB browser, device management library
Net communication
method:
TCP/IP direct communicate, Virtual serial
Work Mode
TCP server, TCP client, UDP, Real Com Driver
Power Requirement
9～24V DC
Environment
Running temperature:
-40~85℃
Storage temp:
-45~165℃
Humidity:
5~95%RH
4. Instructions
4.1 Hardware

ZLAN 5143D Specifications

General

Brand	ZLAN
Model	5143D
Category	Gateway
Language	English
