19
Step 10: Connecting the Drain Hose
1. Check the parts on the sink to which the drain hose will be connected.
2. There are several ways to insert the drain hose into the drain hose connector of the
sink, as shown in the following figure. You must connect the drain hose in accordance
with the water pipe installation regulations in your region.
Case 1 - Without Disposal
3. Check the size of the sink’s drain hose connector (21mm (0.83 inches)- as shown
in Figure 11 on the next page). If the end of the drain hose does not fit onto the drain
hose connector of the sink, use an adaptor purchasable at a plumbing/hardware
supply store.
4. Slide a hose clamp over the end of the drain hose. Attach the drain hose to the
sink connector, slide the hose clamp to the end of the hose, and then tighten the hose
clamp.
5. If there is no air gap, make sure to hang the middle of the drain hose well above
the sink cabinet base to prevent backflow (see Figure 13 on the next page).
6. When drilling a hole for the drain hose on the cabinet wall, take caution not to
damage the drain hose by sharp edges of the hole. On wooden walls, use sand
paper to soften the edges. On metal walls, use insulation tape or duct tape to cover
the sharp edges around the hole.
7. Take caution not the damage the drain hose when installing the dishwasher on the
floor, wall,or cabinet.
installing the dishwasher
Note :
You must use a hose clamp. Failure to do so may cause water leakage.
To Next Page
