Zte ZXA10 C320 Hardware Description

ZXA10C320HardwareDescription
P2PInterfaceCard.....................................................................................................2-8
PowerCard..............................................................................................................2-10
Backplane................................................................................................................2-12
FanUnit...................................................................................................................
2-13
2.1SMXACard
Overview
TheswitchingandcontrolcardSMXAistheserviceswitching,management,andcontrol
centeroftheZXA10C320.
Panel
Figure2-1showsthepaneloftheSMXAcard.
Figure2-1TheSMXAPanel
Indicators
Table2-2describestheindicatorsontheSMXAcard.
Table2-2SMXAIndicatorsDescription
IndicatorStatusDescription
LEDisOFF.Thepoweroftheequipmentisnotsuppliedfromthepanel,
butcanbesuppliedfromthebackplane.
GreenLEDisON.Thepowersupplyfromthepanelisproper.
PWR
RedLEDisON.Thepowersupplyfromthepanelisproper.
LEDisOFF.Thecardisnotpoweredon,ortheCentralProcessingUnit
(CPU)isnotstarted.
GreenLEDashes
slowly(0.5Hz).
Thecardrunsproperly.
GreenLEDisON.lThecardpassestheselftest,butfailstoobtaindata
fromtheswitchingandcontrolcardorNMS.
lThecardisrunningthebootingprogram,orisdown-
loadingasoftwareversionfromtheswitchingandcon-
trolcard.
lThecardcannotoperatebecausethereisnolegalsoft-
wareversion.
RUN
2-2
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Zte ZXA10 C320 Specifications

General

Product Type	Optical Line Terminal (OLT)
Chassis Height	2U
Service Slots	2
Uplink Slots	2
Redundancy	Supported
Uplink Ports	4 x 10GE
