Zte ZXA10 C320 Hardware Description

ZXA10C320HardwareDescription
TechnicalSpecication
Table2-12liststechnicalspecicationsoftheFTGKcard.
Table2-12FTGKTechnicalSpecication
ItemSpecication
Powerconsumption85W
Dimensions395.5mm×22.5mm×225mm(Height×Width×Depth)
Weight1.51kg
2.4PowerCard
Overview
ThepowercardPRAMcarduses110Vor220VACpowerandprovidespowersupplyto
eachcard.
Panel
Figure2-8showsthePRAMcardpanel.
Figure2-8PRAMPanel
Indicators
Table2-13describestheindicatorsofthePRAMcard.
Table2-13PRAMIndicatorDescription
IndicatorStatusDescription
GreenLEDison.Powerison. PWR
GreenLEDisoffPowerisabnormal.
GreenLEDison.Thebatteryworksproperly.
GreenLEDashes
quickly.
Thebatteryisdischarging,orthebatteryis
reverselyconnected.
BATTERY
GreenLEDisoff.Thebatteryisnotavailable.
Interfaces
Table2-14describestheinterfacesofthePRAMcard.
2-10
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Zte ZXA10 C320 Specifications

General

Product Type	Optical Line Terminal (OLT)
Chassis Height	2U
Service Slots	2
Uplink Slots	2
Redundancy	Supported
Uplink Ports	4 x 10GE
