ZXA10C320HardwareDescription
3.2NetworkCable
CableStructure
Networkcablesarecat-5cableswithtwoendsofRJ45connectors,seeFigure3-2.
Figure3-2NetworkCableStructure
PinConnections
Table3-2liststhepinconnectionsofanetworkcable.
Table3-2PinConnectionsofaNetworkcable
EndAEndBSignal
RJ45_3(Crossover) RJ45_1
RJ45_1(Straight-through)
TPOP
RJ45_6(Crossover) RJ45_2
RJ45_2(Straight-through)
TPOP
RJ45_1(Crossover) RJ45_3
RJ45_3(Straight-through)
TPIP
RJ45_2(Crossover) RJ45_6
RJ45_6(Straight-through)
TPIN
3-2
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential
