Zte ZXA10 C320 Hardware Description

ZXA10C320HardwareDescription
2.3P2PInterfaceCard
Overview
TheFTGKcardisa48-portP2Pinterfacecard.ItusesWDMtechnologyandsingleoptical
berfortransmittingandreceiving.
Panel
Figure2-6showstheFTGKpanel.
Figure2-6FTGKPanel
Indicator
Table2-10describestheindicatorsoftheFTGKcard.
Table2-10FTGKIndicatorDescription
IndicatorStatusDescription
LEDisOFF.Thecardispoweredoff,orCPUisnotstarted.
GreenLEDisON.lThecardpassestheselftest,butfailstoobtaindata
fromtheswitchingandcontrolcardorNMS.
lThecardisrunningthebootingprogram,oris
downloadingasoftwareversionfromtheswitching
andcontrolcard.
lThecardcannotoperatebecausethereisnolegal
softwareversion.
GreenLEDashes
quickly.
Thecardisdownloadingdatafromtheswitchingand
controlcardortheNMS.
GreenLEDashes
slowly(0.5Hz).
Thecardrunsproperly.
RedLEDisON.lAseriousfaultoccurstothehardwareofthecard(such
as,thecardfailstopasstheselftest,orthesoftware
versionisincompatiblewiththehardwareversion).
lTheNMSissendingarestartingcommand.
RedLEDashes
slowly(0.5Hz).
Thiscardshouldnotbeinsertedinthisslot(differentfrom
thecongurationoftheNMS).
RUN
YellowLEDashes
slowly(0.5Hz).
Thesoftwareversionofthecardisincompatiblewiththat
oftheswitchingandcontrolcard(auto-updatefunctionis
notconguredonthecard).Theservicesareproper.
2-8
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential

Zte ZXA10 C320 Specifications

General

Product Type	Optical Line Terminal (OLT)
Chassis Height	2U
Service Slots	2
Uplink Slots	2
Redundancy	Supported
Uplink Ports	4 x 10GE
