Chapter3Cables
Note:
Thenetworkcablecannotbelongerthan100m.
3.3SerialPortCable
CableStructure
Figure3-3showstheserialportcablestructure.EndAisaRJ45connectorandEndBis
aDB9connector.
Figure3-3SerialPortCableStructure
PinConnections
Table3-3listspinconnectionsoftheserialportcable.
Table3-3PinConnectionsoftheSerialPortCable
EndAEndB
33
45
55
62
Note:Otherpinsarenull.
3-3
SJ-20130520170233-004|2013-08-31(R1.0)ZTEProprietaryandCondential
