Zte ZXR10 2928E User Manual

Chapter4ServiceConguration
CommandFunction
zte(cfg)#setethernet-oamport<portlist>link-monitor{enable|disable}
Enablesordisableslinkmonitor
function.
zte(cfg)#setethernet-oamport<portlist>link-monitorsymbol-period
threshold<1-65535>window<1-65535>
Setsthesymbolperiodeventwhichis
usedforlinkmonitor.
zte(cfg)#setethernet-oamport<portlist>link-monitorframethreshold
<1-65535>window<1-60>
Setstheerrorframe.
zte(cfg)#setethernet-oamport<portlist>link-monitorframe-period
threshold<1-65535>window<1-600000>
Setstheperiodoferrorframe.
zte(cfg)#setethernet-oamport<portlist>link-monitorframe-seconds
threshold<1-900>window<10-900>
Setserrorframesummary.
showethernet-oam(allcongurationmodes)
DisplaysOAMglobalconguration
information.
showethernet-oamport(allcongurationmodes)
DisplaysOAMportsummary
information.
showethernet-oamport<portlist>discovery(allcongurationmodes)DisplaysportOAMdiscoverystate.
showethernet-oamport<portlist>statistics(allcongurationmodes)
DisplaysportOAMstatistics
information.
showethernet-oamport<portlist>link-monitor(allcongurationmodes)
DisplaysportOAMlinkevent
congurationandstate.
OAMRemoteLoopbackCongurationInstance
lCongurationDescription
OAMmonitorfunctioncannotifytheabnormalframeoflinkreceivertothelocal.The
functionisbasedonOAMdiscovery.AsshowninFigure4-45,Theuserlogsinto
theswitchthroughconsoleportandconguresOAM.EnableOAMandtheportlink
monitoroftheotherend.Thentheerrorframeandtheerrorsymbolcanbedetected
andnotifylocalswitch.
Figure4-45RemoteLoopNetwork
lCongurationProcedure
1.CongurationofswitchA:
zte(cfg)#setethernet-oamen
zte(cfg)#setethernet-oamport1en
2.CongurationofswitchB:
4-113
SJ-20120409144109-002|2012-07-02(R1.0)ZTEProprietaryandCondential
