ZXRAN V9200 Product Description
ZTE Confidential & Proprietary 15
2.2.2.1 VBPc0
VBPc0 is a baseband processing board for 2G/3G/4G multi-mode, whose capacity is
specified in Table 2- 5.
Table 2- 5 VBPc0 Capacity
Mode
Capacity
GSM
72 TRXs
UMTS
24 CSs (1536 CEs)
LTE
12 20MHz Cells, DL 1.8 Gbps/UL 900 Mbps
GU dual-mode
36 GSM TRXs + 12 UMTS CSs(768 CEs),
Or 12 GSM TRXs + 18 UMTS CSs(1280 CEs),
Or 24 GSM TRXs + 12 UMTS CSs(1024 CEs)
GF dual-mode
36 GSM TRXs + 6 FDD LTE Cells,
Or 12 GSM TRXs + 9 FDD LTE Cells
UF dual-mode
12 UMTS CSs (768 CEs) + 6 FDD LTE Cells,
Or 6 UMTS CSs (384 CEs) + 9 FDD LTE Cells,
FI dual-mode
12 FDD LTE Cells + 6 NB-IoT Carriers
FT dual-mode
6 FDD LTE Cells + 6 TDD LTE Cells
GUF multi-mode
12 GSM TRXs + 6 UMTS CSs (512 CEs) +6 FDD LTE Cells,
Or 12 GSM TRXs + 12 UMTS CSs (768 CEs) +3 FDD LTE Cells
GFI multi-mdoe
18 GSM TRXs + 6 FDD LTE Cells + 6 NB-IoT Carriers,
Or 12 GSM TRXs + 9 FDD LTE Cells + 3 NB-IoT Carriers
UFI multi-mode
12 UMTS CSs (768 CEs) + 6 FDD LTE Cells+ 3 NB-IoT Carriers
GUI multi-mode
36 GSM TRXs + 6 UMTS CSs (384 CEs) + 6 NB-IoT Carriers
FTI multi-mode
6 FDD LTE Cells + 6 TDD LTE Cells + 3 NB-IoT Carriers
GUFI
multi-mode
18 GSM TRXs + 6 UMTS CSs (384 CEs) + 6 FDD LTE Cells + 3
NB-IoT Carriers,
Or 12 GSM TRXs + 6 UMTS CSs (512 CEs) + 6 FDD LTE Cells +
3 NB-IoT Carriers
Note: 1. The above table describes the maximum hardware capability. The actual capability is up to
the licenses configured. 2. LTE can be FDD LTE or TDD LTE, where FDD LTE supports
