ZXRAN V9200 Product Description
40 ZTE Confidential & Proprietary
Figure 4- 11 Appearance of VC9182 (with 1 DCPD and 1 V9200)
1. DCPD 2. V9200
The physical specifications of the VC9182 are specified in Table 4- 7.
Table 4- 7 Physical Specifications of VC9182
Item
Description
Dimension (mm) (H x W x D)
600 x 220 x 500
Rack Weight (kg)
10.4 kg (Without the door)
11.7 kg (With the door)
Inner Space
4 U
4.6 Indoor L-Rack-I1
In the indoor scenario, the V9200 is typically put in the indoor L-Rack-I1, as shown in
Figure 4- 12. One L-Rack-I1 maximally supports 2 BBUs, 1DCPD and dual-layer 6 RRUs
or single-layer 3 RRUs. There is still at least 9U spare room reserved for other equipment,
including transmission devices etc.
