Chapter 1 –Introduction
ACS/ACC/ACP 604/607 Drives ACx=ACS/ACC/ACP 1-3
Inquiries
Any inquiries about the product should be addressed to the local
distributor or ABB representative, quoting the type code and the serial
number of the unit. If the local ABB representative cannot be
contacted, inquiries should be addressed to directed to the address
and phone numbers on the back cover of this manual.
17 Degree of Protection
Appendix A:
Enclosures
0 = IP 00 (chassis), A = IP 21, 2 = IP 22, 4 = IP 42,
5 = IP 54, 6 = IP 00 with Coated Boards,
7 = IP 22 with Coated Boards,
8 = IP 42 with Coated Boards
9 = IP 54 with Coated Boards
B = IP 21 with Coated Boards
18 Line Input and Protection Options
19 Starter for Auxiliary Motor Fan
20 Filters
Appendix A:
CE marking
0 = CE with EMC Filters (not for 690V or 12-pulse
rectifier)
3 = CE with output du/dt Filters + EMC Filters (not for
690V)
5 = Output du/dt Filters + no EMC Filters
8 = No CE, no EMC filters, US conduit (ACS 607 only,
115 VAC transformer secondary; compliant with
NFPA 90)
9 = CE Low Voltage and Machinery Directives; No EMC
(ACS 607 only, secondary of all transformers
220 VAC)
21 Braking Chopper and Cabling Direction
22 Other Options
Character
no.
Meaning Refer to
