Chapter 2 – Mechanical Installation
2-2 ACx=ACS/ACC/ACP ACS/ACC/ACP 604/607 Drives
enclosure.
Do not mount the drive on any surface with temperature exceeding
the allowable air temperature.
Do not mount the drive in direct sunlight.
Do not mount the drive where it will be subjected to excessive
vibration. (A-12)
Installation Procedure
ACx 607
It is advisable to secure the cabinet to the floor with bolts through the
holes at its base or with fastening hooks attached to its bottom front
and back edges. This is especially important in installations subjected
to vibration or other movement.
1. Check the intended installation site for sufficient room. Check that
there is nothing on the floor to inhibit installation. See
Appendix B –
ACx 607 Dimensional Drawings
for cabinet details. Mark the
locations for the mounting holes (and the cable duct opening).
2 Make mounting holes according to the dimensional drawings.
Smooth cable duct edges if required. Install bolt anchors in the
mounting holes.
3 Place the drive carefully onto the holes
4 Place bolts in the bolt anchors.
5. Tighten the bolts.
