Appendix A – ACS/ACC/ACP 604/607 Technical Data
ACS/ACC/ACP 604/607 Drives ACx=ACS/ACC/ACP A-15
NIOC and NIOCP
Board Specifications
Data of the external control connection boards of the ACS 600 product
family are given below.
ACS/ACC/ACP 600
NIOC-01 Board
ACP 600
NIOCP-01 Board
Analog Inputs
The advantage of the
differential analog
input is that the
ground potential of
the device or
transmitter sending
an analog signal can
differ up to ± 15 V
from the ground
potential of the
ACx 600 chassis
without disturbing the
signal. Differential
input also efficiently
attenuates common
mode disturbances
coupled to control
cables.
ACS 600: Two Programmable Differential
Current Inputs: 0 (4) to 20 mA,
R
in
= 100 Ω
ACC 600: Two Differential Current Inputs:
0 to 20 mA,
R
in
= 100 Ω
ACP 600: One Programmable Differential
Current Input: 0 to 20 mA,
R
in
= 100 Ω
ACS/ACP 600: One Programmable
Differential Voltage Input: ACS 600: 0 (2) to
10 V,
R
in
> 200 kΩ; ACP 600: 0 to 10 V, R
in
>
200 kΩ
ACC 600: One Differential Voltage Input: 0
to 10 V,
R
in
> 200 kΩ
Common Mode Voltage:
± 15 VDC, max.
Common Mode Rejection Ratio: > 60 dB at
50 Hz
Resolution: 0.1 % (10 bit)
Inaccuracy:
± 0.5% (Full Scale Range) at
77
°F(25°C). Temperature Coefficient:
± 200 ppm/°C,(110ppm/°F) max.
Input Updating Time: 12 ms (ACS 600),
44 ms (ACC 600), 1 ms (ACP 600)
Two Bipolar Differential Voltage Inputs:
± 10 V, R
in
= 30 kΩ
Common Mode Voltage:
± 20 VDC, max.
Common Mode Rejection Ratio: >
60 dB at
50 Hz
Resolution: 0.02 % (12 bit)
Accuracy: 11 bit
Inaccuracy:
± 0.1% (Full Scale Range) at
77
°F(25°C)Temperature Coefficient:
± 100 ppm/°C (56ppm/°F), max.
Input Updating Time: 1 ms
Constant Voltage
Output
Voltage: 10 VDC ± 0.5% (Full Scale Range) at
77 °F(25
°C). Temperature Coefficient:
± 100 ppm/°C, max.
Maximum Load: 10 mA
Applicable Potentiometer: 1 kΩ to 10 kΩ
Voltage: ± 10 VDC ± 0.5% (Full Scale Range)
at 77 °F(25°C). Temperature Coefficient:
± 100 ppm/°C 56ppm/
°F), max.
Maximum Load: 10 mA
Applicable Potentiometer: > 1 kΩ
Auxiliary Power
Output
Voltage: 24 VDC ± 10% Short circuit proof
Maximum Current: 250 mA (130 mA with
NLMD-01 option)
Voltage: 24 VDC ± 10% Short circuit proof
Maximum Current: 250 mA
Analog Outputs ACS/ACC 600: Two Programmable Current
Outputs: 0 (4) to 20 mA,
R
L
< 700 Ω
ACP 600: One Programmable Current
Output: 0 to 20 mA,
R
L
< 700 Ω
Resolution: 0.1 % (10 bit)
Inaccuracy:
± 1% (Full Scale Range) at77 °F
(25
°C). Temperature Coefficient:
± 200 ppm/°C, max.
Output Updating Time: 24 or 100 ms
(ACS 600), 44 ms (ACC 600), 8 ms (ACP 600)
One Bipolar Programmable Voltage Output:
+ 10 V, R
L
> 2kΩ
Resolution: 0.02% (12 bit)
Accuracy: 10 bit
Inaccuracy:
± 0.1% (Full Scale Range) at77
°F (25
°C). Temperature Coefficient:
± 200 ppm/°C, max.
Output Updating Time: 2ms
Output Rising Time: 3ms
