ABB ACS320 series User Manual

40 Actual signals and parameters in the short view
14 RELAY OUTPUTS Status information indicated through relay output, and relay
operating delays. For more information, see chapter Actual
signals and parameters in ACS320 user’s manual
(3AUA0000062599 [English]).
1401 RELAY
OUTPUT 1
Selects a drive status indicated through relay output RO 1.
The relay energizes when the status meets the setting.
READY
NOT SEL Not used 0
READY Ready to function: Run enable signal present, no fault
exists, supply voltage is within range, and emergency stop
command is not On.
1
RUN Running: Energize relay when power is applied. 2
FAULT(-1) Inverted fault. Energize relay when power is applied. De-
energizes when a fault occurs.
3
16 SYSTEM
CONTROLS
Parameter view, Run enable, parameter lock etc.
1611 PARAMETER
VIEW
Selects the parameter view, i.e, which parameters are
shown on the control panel.
SHORT
VIEW
FLASHDROP Shows the FlashDrop parameter list. Does not include the
short parameter list. Parameters which are hidden by the
FlashDrop device are not visible.
FlashDrop parameter values are activated by setting
parameter 9902 APPLIC MACRO to 31 (LOAD FD SET).
1
SHORT VIEW Shows only those signals and parameters that are listed in
this table.
2
LONG VIEW Shows all signals and parameters. See chapter Actual
signals and parameters in ACS320 user’s manual
(3AUA0000062599 [English]).
3
20 LIMITS Drive operation limits
2008 MAXIMUM
FREQ
Defines the maximum limit for the drive output frequency. E: 50.0 Hz
U: 60.0 Hz
0.0…500.0 Hz Maximum frequency 1 = 0.1 Hz
21 START/STOP Start and stop modes of the motor
2102 STOP
FUNCTION
Selects the motor stop function. COAST
COAST Stop by cutting off the motor power supply. The motor
coasts to stop.
1
RAMP Stop along a ramp. See parameter group 22
ACCEL/DECEL.
2
Parameters in the short parameter view
No. Name/Value Description Def/FbEq

ABB ACS320 series Specifications

General

Voltage Range	200 V to 240 V, 380 V to 480 V
Control Method	Scalar control
Protection Class	IP20
Frequency	48 to 63 Hz
Communication Protocols	Modbus RTU
Enclosure Rating	IP20
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m without derating
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Ambient Temperature	-10°C to +40°C (derating above +40°C)

Summary

Safety

Safety in installation and maintenance

Covers essential safety instructions for installation, operation, and maintenance.

Safe start-up and operation

Guidelines for safely starting up and operating the drive.

Hardware Description

Power connections and control interfaces

Diagrams and explanations of drive power and control connections.

Type designation label

Type designation key

Mechanical Installation

Installing

Instructions for mounting the drive using screws or DIN rail.

Electrical Installation

Checking the compatibility with IT (ungrounded) and corner-grounded TN systems

Connecting the power cables

Procedure for connecting input and output power cables to the drive.

Connecting the control cables

Wiring instructions for digital and analog control signals.

Start-up and Control with I/O

How to start up the drive

Steps for initial drive start-up, including manual and guided methods.

How to perform a manual start-up

Detailed steps for manual start-up using the control panel.

How to perform a guided start-up

How to control the drive through the I/O interface
