Resistor braking
121
P
brcont
The drive and the chopper will withstand this continuous braking power. The braking is considered continuous if the braking time
exceeds 30 s.
Note: The braking energy transmitted to the specified resistor(s) in 400 seconds may not exceed E
R
.
R Resistance value for the listed resistor assembly. Note: This is also the minimum allowed resistance for the brake resistor.
E
R
Short energy pulse that the resistor assembly withstands every 400 seconds. This energy will heat the resistor element from 40 °C
(104 °F) to the maximum allowable temperature.
P
Rcont
Continuous power (heat) dissipation of the resistor when placed correctly. Energy E
R
dissipates in 400 seconds.
All braking resistors must be installed outside the converter module. The SACE braking resistors are built in an IP 21 metal housing. The
SAFUR braking resistors are built in an IP 00 metal frame.
400 V units
-0003-3 1.1 SACE08RE44 44 210 1
-0004-3 1.5 SACE08RE44 44 210 1
-0005-3 2.2 SACE08RE44 44 210 1
-0006-3 3.0 SACE08RE44 44 210 1
-0009-3 4.0 SACE08RE44 44 210 1
-0011-3 5.5 SACE15RE22 22 420 2
-0016-3 7.5 SACE15RE22 22 420 2
-0020-3 11 SACE15RE22 22 420 2
-0025-3 23 SACE15RE13 13 435 2
-0030-3 28 SACE15RE13 13 435 2
-0040-3 33 SAFUR90F575 8 1800 4.5
-0050-3 45 SAFUR90F575 8 1800 4.5
-0060-3 56 SAFUR90F575 8 1800 4.5
-0070-3 68 SAFUR80F500 6 2400 6
-0100-3 83 SAFUR125F500 4 3600 9
-0120-3 113 SAFUR125F500 4 3600 9
500 V units
-0004-5 1.5 SACE08RE44 44 210 1
-0005-5 2.2 SACE08RE44 44 210 1
-0006-5 3.0 SACE08RE44 44 210 1
-0009-5 4.0 SACE08RE44 44 210 1
-0011-5 5.5 SACE08RE44 44 210 1
-0016-5 7.5 SACE15RE22 22 420 2
-0020-5 11 SACE15RE22 22 420 2
-0025-5 15 SACE15RE22 22 420 2
-0030-5 28 SACE15RE13 13 435 2
-0040-5 33 SACE15RE13 13 435 2
-0050-5 45 SAFUR90F575 8 1800 4.5
-0060-5 56 SAFUR90F575 8 1800 4.5
-0070-5 68 SAFUR90F575 8 1800 4.5
-0100-5 83 SAFUR125F500 4 3600 9
-0120-5 113 SAFUR125F500 4 3600 9
-0140-5 135 SAFUR125F500 4 3600 9
690 V units
-0011-7 5.5 SACE08RE44 44 248 1
-0016-7 7.5 SACE08RE44 44 248 1
-0020-7 11 SACE08RE44 44 248 1
-0025-7 15 SACE08RE44 44. 248 1
-0030-7 18.5 SACE15RE22 22 497 2
-0040-7 22 SACE15RE22 22 497 2
-0050-7 30 SAFUR90F575 8 1800 4.5
-0060-7 37 SAFUR90F575 8 1800 4.5
-0070-7 45 SAFUR90F575 8 1800 4.5
-0100-7 55 SAFUR80F500 6 2400 6
-0120-7 75 SAFUR80F500 6 2400 6
PDM code 00096931-G
ACS 800-01 type Braking power of
the chopper and the
drive
Brake resistor(s)
P
brcont
(kW)
Type R
(ohm)
E
R
(kJ)
P
Rcont
(kW)
