Inquiries
Address any inquiries about the product to the local ABB representative, quoting the
type code and the serial number of the unit. If the local ABB representative cannot
be contacted, address inquiries to the manufacturing facility (addresses and phone
numbers are on the back cover of this manual).
Check the insulation of the motor and the motor
cable.
Installation: Checking the insulation of the
assembly
If the drive is about to be connected to an IT
(ungrounded) system, check that the drive is not
equipped with EMC filter +E202.
The ACS800-02/U2: Type code. For
instructions on how to disconnect the EMC
filtering, contact ABB.
Route the cables. Planning the electrical installation: Routing the
cables
For compliance with the European Union EMC
Directive, see Technical data: CE marking
Install the drive. Connect the power cables. Connect
the control and the auxiliary control cables.
Installation, Resistor braking (optional)
Check the installation. Installation checklist
Commission the drive. Appropriate firmware manual
Commission the optional brake chopper (if present). Resistor braking
Task See
