ABB ACS880 P944 Series User Manual

ACS880-01… +P944
UL Type OpenIP 20Frame
Weight
lb
Depth
in.
Width
in.
Height
in.
Weight
kg
Depth
mm
Width
mm
Height
mm
179.826.1014.807.6249155376R2
2210.296.8117.179.9261173436R3
3710.807.9922.1716.8274203563R4
4510.777.9925.7020.2274203653R5
8814.079.9222.3539.8357252593R6
10714.3511.1825.3948.6365284645R7
13215.2111.8128.059.8386300724R8
19116.2714.9628.4686.6413380723R9
ACS880-11… and ACS880-31… +P940
UL Type OpenIP 20Frame
Weight
lb
Depth
in.
Width
in.
Height
in.
Weight
kg
Depth
mm
Width
mm
Height
mm
4013.787.9919.2918.3349203490R3
10314.099.9230.3559358252771R6
24016.9411.8137.95109430300964R8
For more information on dimensions, see the dimension drawings.
200 mm (7.87 in.) free space is required at top of the drive module.
300 mm (11.81 in.) free space is required at bottom of the drive module.
Degree of protection
IP20 (UL Type Open).
