Aztec 600 aluminium, ammonia, color, iron, manganese, phosphate
Single- and multi-stream colorimetric analyzers 6 Configuration
36 IM/AZT6CR–EN Rev. J
6.5 Current Outputs
There are seven tabs in the Outputs screen, one for each output and an output calibration tab:
6.5.1 Outputs 1 to 6
6.5.2 Output Calibration
Fields Description
Output Source
The 'Output Source' field has several options:
None – no other fields are visible
Stream 1 to Stream 3
The following fields are displayed only if 'Output Source' is set to 'Stream X':
Output Range
The high and low limits for the output range. Both values can be set independently.
If the difference between the zero and span is too small, the output is very noisy.
Output Type
The electrical high and low limits (0 to 22 mA).
For example, if the output range is set to 0 to 2000 ppb and the 'Output Type' to 4.00 to 20.00 mA,
at 0 ppb the output is 4.00 mA and at 2000 ppb the output is 20.00 mA.
Calibration Hold If set to 'Yes', the output value remains at the level prior to calibration.
Out of Sample Ind.
Out of sample indicator. If set to 'Yes', the output goes to the default output value when an out of
sample condition occurs for the selected stream source.
The following field is displayed only if 'Out of Sample Ind.' is set to 'Yes':
Default Output The output value used when an out of sample condition occurs and 'Out of Sample Ind.' is set to
'Yes' (0 to 22 mA).
Fields Description
Calibrate Output 1 (to 6) Enables each output to be calibrated.
