Aztec 600 aluminium, ammonia, color, iron, manganese, phosphate
Single- and multi-stream colorimetric analyzers 12 Diagnostic Information and Icons
IM/AZT6CR–EN Rev. J 57
Calibration Failed
The analyzer has failed calibration.
1. Check that the reagents are of the correct type, connected
correctly (Reagent 1 to valve R1 etc.) and are within their shelf life.
If it is possible that the reagents have become contaminated
replace them.
2. Check that the calibration settings are correct.
3. Check for any restrictions or blockages in the analyzer tubing or
valve manifold.
4. Check that each reagent/sample is drawn into the measurement
head correctly with no air bubbles.
5. Check the optical cell for any scratches.
If the error still exists contact the local ABB representative.
OFF OFF OFF ON
Calibration Failed
The analyzer has failed calibration.
If the Calibration Fail Event has been set to Attention from the default Fail,
the analyzer continues to measure after a failed calibration using the last
valid calibration.
OFF ON OFF OFF
Calibration Standard Empty
The calibration standard bottle is empty.
Replace the calibration solution.
OFF OFF OFF ON
Cleaning
A clean routine is being run.
ON OFF OFF OFF
Critical Temperature Reached
This alarm is initiated if the analyzer temperature rises above 60 °C
(140 °F) during temperature control.
1. Check that the ambient temperature limits have not been
exceeded.
2. Contact the local ABB representative.
OFF OFF OFF ON
DI Empty
The de-ionised water bottle is empty.
Replace the de-ionised water.
OFF OFF OFF ON
Excessive Secondary Current in Electronics
Too much current is being drawn by the electronics in the system; this
causes the analyzer to go into automatic shutdown.
Contact the local ABB representative.
OFF OFF OFF ON
Icon Diagnostic message
Stop
Relay
Attention
Relay
Calibration
Relay
Failure
Relay
Table 12.1 Diagnostic Information, Relay Operations and Inhibits (Sheet 2 of 5)
To Next Page
