Machine description
1 Type of motor
2 Motor number (specific for each motor)
3 Rating and performance standard
4 Mounting arrangement
5 Thermal class/Temperature rise
6 Motor weight (without cooling device)
7 Converter and/or AC supply data
9 Machine type
10 Duty cycle
11 Application
12 No. of brushes/arm on brush gear
13 Branch
14, 18, 22, 26 Mechanical power (kW) heater
15, 19, 23, 27 Armature DC voltage
16, 20, 24, 28 Armature DC current
17, 21, 25, 29 Speed (rpm)
30 Field exciter voltage
31 Field exciter current
32 Catalogue no.
33 Alternative duty cycle
34 Open row
35 No. of brushes/arm on brush gear,
alternative operation
36 Alternative machine type
37, 41, 45, 49 Mechanical power (kW) for alternative
operation
38, 42, 46, 50 Armature DC voltage for alternative
operation
39, 43, 47, 51 Armature DC current for alternative
operation
40, 44, 48, 52 Speed (rpm) for alternative operation
53 Field exciter voltage, alternative
operation
54 Field exciter current, alternative
operation
55 Open row
56 Method of cooling
57 Degree of protection
58 Valid temp. range for operation
59 Motor end for cooling air intake
60 Volume of cooling air
(for heat dissipation)
61 Static air pressure drop
62 Key type used for balancing
63 Balancing class
64 Number of phases connected to
standstill heater
65 Standstill heater voltage
66 Standstill heater power
67 Lubrication interval
68 Grease quantity
69 Bearing type at D-end
70 Bearing type at N-end
71 Manufacturing year
72 Open row
73 Valid altitude for motor operation
74, 75, 76, 77 Mechanical power (HP)
78, 79, 80, 81 Mechanical power (HP), alternative
operation
82 Open row
83 CSA logotype (if CSA approved)
