ABB DCS880 User Manual

20
Using the control panel
3ADW000480R0101 DCS880 Quick guide e a
DCS880 Set up control panel assistant
General display features
Following modes are available in the MAIN MENU:
1. Parameters mode
2. Start-up assistants mode
a. Name plate data
b. Autotuning field current controller
c. Autotuning armature current controller
d. First motor tuning
e. Speed feedback assistant
(Tacho fine tuning not available)
f. Autotuning speed controller
g. Field weakening assistant
(only used when maximum speed is higher
than base speed)
h Make a back up
Parameters entered by assistant
99.07
M1 used field exciter type
99.10
Nominal mains voltage
99.11
M1 nominal current
99.12
M1 nominal voltage
99.13
M1 nominal field current
99.14
M1 nominal base speed
30.11
M1 minimum speed
30.12
M1 maximum speed
30.19
Minimum torque 1
30.20
Maximum torque 1
30.35
M1 current limit bridge 1
30.34
M1 current limit bridge 2
31.30
M1 overspeed trip margin
31.44
Armature overcurrent level
94.23
OnBoard encoder pulses/revolution
94.24
OnBoard encoder type
94.25
OnBoard encoder speed calc type
94.07
M1 tacho type
94.08
M1 tacho voltage at 1000 rmp
90.41
M1 feedback selection
23.12
Acceleration time 1
23.13
Deceleration time 1
31.58
M1 field current low level
28.17
M1 EMF/field control mode
