Type code
3ADW000480R0101 DCS880 Quick guide e a
Type code
The type code contains information on the specification and configuration of the drive. The first digits from left
show the basic configuration (e.g. DCS880-S01-2000). The optional selections are given thereafter on the
name plate by plus code. The main selections are described below. Not all selections are available for all
types.
The drive's basic type code: DCS880-AAB-CCCC-DDEF + plus code
Product family
DCS8
80
Product type:
AA
= S0
= R0
= E0
= A0
Standard converter module
Rebuild kit
Panel solution
Enclosed converter
Bridge type:
B
= 1
= 2
Single bridge (2-Q)
2 anti-parallel bridges (4-Q)
Module type:
CCCC
=
Rated DC current (IP00)
Rated AC voltage:
DD
= 04
= 05
= 06
= 07
= 08
= 10
= 12
100 V
AC
- 415 V
AC
100 V
AC
- 525 V
AC
270 V
AC
- 600 V
AC
315 V
AC
- 690 V
AC
360 V
AC
- 800 V
AC
450 V
AC
- 990 V
AC
540 V
AC
- 1200 V
AC
Power connection:
E
= X
= L
= R
Standard H1 ... H7
Left side H8
Right side H8
Revision code:
F
= 0
1
st
generation
Field exciter
configuration:
+0S163
+S164
H1 ... H4 without OnBoard field exciter
H5 and H6 with internal field exciter, supply external
(H5 and H6: 25 A, Rebuild kit: 16 A / 25 A)
Fan voltage:
Standard
+S171
Size H4
Fan voltage: 230 V / 1-ph
Fan voltage: 115 V / 1-ph
Application
programming
+S551
Memory unit including drive application programming license
Current
measurement:
+S175
SDCS-CMA-2 (H6 ... H8)
Voltage
measurement:
+S186
+S185
+S183
+S189
120 V SDCS-SUB-4 (H1 ... H5)
SDCS-PIN-H51 configured to 120 V (H6 ... H8)
SDCS-PIN-H51 configured to 990 V (H6 ... H8), 12-pulse serial /
serial sequential
SDCS-PIN-H51 configured to galvanic isolation (H6 ... H8)
SDCS-DSL-H1x:
+S521
+S522
+S523
1 DCSLink channel, 0 channels optical power link SDCS-DSL-H10
1 DCSLink channel, 2 channels optical power link SDCS-DSL-H12
1 DCSLink channel, 4 channels optical power link SDCS-DSL-H14
Control panel:
+0J404
+J428
+J429
Without control panel
daisy-chain option DPI-H01 kit
Bluetooth control panel ACS-AP-W
The technical data and specifications are valid as of going to press. ABB reserves the right to make
subsequent alterations.
