Environmental conditions
3ADW000480R0101 DCS880 Quick guide e a
Environmental conditions
System connections
Environmental limit values
Voltage, 3-phase:
100 ... ≤ 1000 V acc. to IEC 60038
Permissible cooling air temp.
Voltage deviation:
±10 % continuous; ±15% short-time *
- at converter module air inlet:
0 ... +55°C
Rated frequency:
50 Hz or 60 Hz
with rated DC current:
0 ... +40°C
Static frequency deviation:
50 Hz ± 2 %; 60 Hz ± 2 %
with different DC current:
+30 ... +55°C
Dynamic: frequency range:
50 Hz ± 5 Hz; 60 Hz ± 5 Hz
- Options:
0 ... +40°C
df/dt:
17 % / s
Relative humidity (at 5...+40°C):
5 ... 95 %, no condensation
* = 0.5 ... 30 cycles
Relative humidity (at 0...+5°C):
5 ... 50 %, no condensation
Please note: Special consideration must be taken for voltage
deviation in regenerative mode.
Change of the ambient temp.:
< 0.5°C / minute
Storage temperature:
-40 ... +55°C
Degree of protection
Transport temperature:
-40 ... +70°C
Pollution degree (IEC 60664-1,
IEC 60439-1).
2
Converter module and
options (line chokes, fuse
holder, field exciter, etc.):
IP 00
Site elevation
Enclosed converters:
IP 20/21/31/41
< 1000 m above M.S.L.:
100 %, without current reduction
Paint finish
> 1000 m above M.S.L.:
with current reduction,
Converter module: Body RAL 7012;
Cover RAL 9017 & RAL 9002
Enclosed converter:
Light grey RAL 7035
Sound pressure level and vibration
Size
Sound pressure level L
P
(1 m distance)
Vibration
as module
enclosed conv.
as module
H1
55 dBA 68 dBA
3 mm, 2 … 9 Hz
1 g, 9 ... 200 Hz
H2
55 dBA
72 dBA
H3
60 dBA
78 dBA
H4
66 ... 70 dBA,
depending on fan
77 dBA
North American Standards
In North America the system components fulfil the
requirements of the table below
Rated supply
voltage
Standards
Converter module
Enclosed converter
to 990 V UL 61800-5-1
Power Conversion Equipment
CSA C 22.2 No. 274-13
Industrial Control Equipment,
Industrial Products
Available for converter
modules including field exciter
units. Types with UL mark:
• see UL Listing www.ul.com /
certificate no. E196914
• or on request
UL/CSA types: on
request
