Start-up 61
51.02 FBA PAR2
(NODE ADDRESS)
3
2)
Defines the PROFIBUS
node address of the
fieldbus adapter module.
51.03 FBA PAR3
(BAUD RATE)
12000
1)
Displays the current baud
rate on the PROFIBUS
network in kbit/s.
51.04 FBA PAR4
(TELEGRAM TYPE)
2 (= PPO2)
1)
Displays the telegram type
selected by the PLC
configuration tool.
51.05 FBA PAR5
(PROFILE)
0 (= PROFIdrive) Selects the Control word
according to the
PROFIdrive profile (speed
control mode).
52.01 FBA DATA IN1 4 (= SW 16bit)
1)
Status word
52.02 FBA DATA IN2 5 (= Act1 16bit) Actual value 1 (speed)
52.03 FBA DATA IN3 122
2)
Power
52.05 FBA DATA IN5 107
2)
DC bus voltage
53.01 FBA DATA OUT1 1 (= CW 16bit)
1)
Control word
53.02 FBA DATA OUT2 2 (= Ref1 16bit) Reference 1 (speed)
53.03 FBA DATA OUT3 2508
2)
Constant speed
53.05 FBA DATA OUT5 2410
2)
Speed reference for
Jogging function 1
51.27 FBA PAR
REFRESH
REFRESH Validates the FPBA-01
configuration parameter
settings.
10.01 EXT1 START
FUNC
FBA Selects the fieldbus
interface as the source of
the start and stop
commands for external
control location 1.
10.08 FAULT RESET
SEL
P.FBA MAIN
CW.8
Selects the fieldbus
interface as the source for
fault reset.
Drive parameter Setting for
ACSM1 drives
Description
