- 18 -
000824AG
2 - Characteristics
Communication board
33
Alarm terminal block
37
Remote ON/OFF terminal block
41
USB connector
34
RS485 ABB service 120Ohm
termination res. (service only)
38
RS485 line terminal block
42
SD card slot
35
RS485 line 120Ohm termination res.
39
Ethernet connector 2 (RJ45)
43
CR2032 Backup battery
36
ABB RS485 service Ethernet
connector (RJ45) (service only)
40
Ethernet connector 1 (RJ45)
J2 X1
X2
S5S4
J7
J1
J5 J6
1
2
1
8
7
432
ZGN.V2Q15.2
33 38 39 40 41 4237
34 35
36
43
