40 Quick Installation Guide - PVS-175-TL “A.1 Version”
EN
14. Technical data table
PVS-175-TL
INPUT
Absolute maximum input voltage (Vmax,abs) 1500 Vdc
Input start-up voltage (Vstart) 750 V (650 - 1000 V)
Input operating interval (Vdcmin...Vdcmax) 600 - 1500V
Rated input voltage (Vdcr) 1100 Vdc
Input nominal power(Pdcr) 188000 W @ 30°C - 177000 W @ 40°C
Number of independent MPPT 12
MPPT DC voltage range (VMPPTmin ... VMPPTmax) to Pacr 850 - 1350 Vdc
Maximum DC input power for each MPPT (Pmppt,max) 20000 W [850V≤VMPPT≤1350V]
Maximum DC input current for each MPPT (Idcmax) 22 A
Maximum short circuit current for each MPPT (Iscmax) 30 A
Maximum return current (AC side vs DC side) Negligible in normal operating conditions (1)
Number of DC input pairs for each MPPT 2
Type of input DC connectors PV quick fit connector
Type of photovoltaic panels that can be connected at input
according to IEC 61730
Class A
Input protection
Reverse polarity protection Yes, from current limited source
Input over voltage protection for each MPPT -
varistor (-S / -S2 models)
2
Input over voltage protection for each MPPT -
plug in modular surge arrester (-SX / -SX2 models)
2 (Type 2)
Photovoltaic array isolation control Yes, according to IEC 62109-2
Residual current monitoring device Yes, according to IEC 62109-2
DC switch rating for each MPPT 20 A/1500 V - 35 A/1250 V - 50 A/1000 V (2)
String current monitoring Input current monitoring per MPPT (12ch)
Arc fault protection Optional
Output
AC Connection to the grid Three phase 3W+PE (TN system)
Nominal AC Output Power (Pacr @cosφ=1) 175 000 W @ 40 °C
Maximum AC Output Power (Pacmax @cosφ=1) 185 000 W @ 30 °C
Maximum apparent Output power (Smax) 185 000 VA
Rated AC Output Voltage (Vacr) 800 V
Output voltage range (Vacmin...Vacmin) 552...960 V (3)
Maximum output current (Iacmax) 134 A
Contribution to short-circuit current 140 A
Rated Output Frequency (fr) 50 Hz / 60 Hz
Output Frequency Range (fmin...fmax) 45...55 Hz / 55…65 Hz (3)
Nominal power factor and setting interval
> 0.995, 0...1 inductive/capacitive
with maximum Smax
Total harmonic distortion of current <3%
Maximum AC Cable outer diameter / multi core 1 x 53 mm (1 x M63 cable gland)
Maximum AC Cable outer diameter / single core 3 x 32 mm (3 x M40 cable gland)
AC Connections Type
Busbar for lug connections with
M10 bolts (included);
Single core cable gland plate with 4
individual AC cable glands: 3 x M40: Ø
22...32mm, 1 x M32: Ø 18...25mm
Multi core cable gland plate (optional)
with 2 individual AC cable glands: 1 x M63:
Ø 37…53mm, 1x M32 Ø 18...25mm)
