1MRS750527-MUM
)HHGHU7HUPLQDO
Technical Reference Manual, General
5()B
21
&RQGLWLRQPRQLWRULQJIXQFWLRQV
The condition monitoring function blocks are documented on the CD-ROM
“Technical Descriptions of Functions” (1MRS750889-MCD).
1)
This function is only supported in the feeder terminal revisions of the Release 2.0 or later, refer to
section “Revision identification” on page 90.
&RPPXQLFDWLRQIXQFWLRQV
The REF 54_ feeder terminal provides the IEC_103, SPA and LON serial
communication protocols.
In a customer-specific feeder terminal configuration, special events can be generated
via an EVENT230 event function. EVENT230 is documented on the CD-ROM
“Technical descriptions of Functions” (1MRS750889-MCD).
For more information about communication in the REF 54_ feeder terminal, refer to
section “Serial communication” on page 60.
*HQHUDOIXQFWLRQV
The general function blocks are documented on the CD-ROM “Technical
Descriptions of Functions” (1MRS750889-MCD).
7DEOH &RQGLWLRQLQJPRQLWRULQJIXQFWLRQVDYDLODEOHIRUWKH5()B
)XQFWLRQ 'HVFULSWLRQ
CMBWEAR1 Circuit-breaker electric wear 1
CMBWEAR2 Circuit-breaker electric wear 2
CMCU3 Supervision function of the energizing current input circuit
CMGAS1 Gas pressure monitoring
CMGAS3
1)
Three-pole gas pressure monitoring
CMSCHED Scheduled maintenance
CMSPRC1 Spring charging control 1
CMTCS1 Trip circuit supervision 1
CMTCS2 Trip circuit supervision 2
CMTIME1 Operate time counter 1 for the operate time used (e.g. motors)
CMTIME2 Operate time counter 2 for the operate time used (e.g. motors)
CMTRAV1 Breaker travel time 1
CMVO3 Supervision function of the energizing voltage input circuit
7DEOH *HQHUDOIXQFWLRQVDYDLODEOHIRUWKH5()B
)XQFWLRQ 'HVFULSWLRQ
INDRESET Resetting of operation indicators, latched output signals, registers
and waveforms i.e. the disturbance recorder
MMIWAKE Activation of HMI backlight
SWGRP1 Switchgroup SWGRP1
SWGRP2 Switchgroup SWGRP2
SWGRP3 Switchgroup SWGRP3
......
SWGRP20 Switchgroup SWGRP20
