23
5. The first digit of the setting value of the parameter to be edited starts to flash.
Use
and to move the cursor and and to increase or decrease the
value. The setting range (for example Year or Minutes) is shown on the right-
hand side of the second line of the display.
6. To store a new value and return the display to the view mode, press
.
7. To exit the setting mode without storing the changes, press
once before
confirming and the display is returned to the view mode.
8. Press
to return the display to the idle mode.
TRIP CIRCUIT SUP
Main Menu
Group Menu
Parameter Menu
Confirm
Cancel
SETTINGS
CONFIGURATION
MEASUREMENTS
RECORDED DATA
FUNCTION TEST/DI
COMMUNICATION
LANGUAGE
FREQUENCY
CONFIGURATION
CONFIGURATION
MEMORY SETTINGS
HMI PASSWORDS
TIME
INFO
YY-MM-DD (00-23)
hh.mm;ss (00-59)
OPERATION
STORE COUNTER
A040238_2
Fig. 4.1.9.-1 Setting the real-time clock
4.1.10. How to reset the trip lockout function
The trip lockout function is used to prevent accidental closing of the circuit breaker
after a trip. The trip lockout function must be locally reset with a separate reset
before the circuit breaker can be closed again.
Reset the trip lockout as follows:
1. Press an arrow button to access the main menu.
2. Use the arrow buttons to select OPERATION\TRIP LOCKOUT\LOCKOUT
RESET.
3. Press
to enter the setting mode. The second line starts to flash.
4. Press
to reset trip lockout.
5. Press
to return the display to the idle mode.
Feeder Protection Relay
Operator's Manual - ANSI Version
REF 610REF 610
1MRS755539
