9
Remote transfer
data
In addition to the event data all input data (I-
data), setting values (S-data), control parameters
(V-data), and some other data of the module
can be read over the SPA bus. Also, part of the
data can be altered by commands given over the
SPA bus.
Data Para- Data Values
meter direct.
Inputs
Aut I1 R 0 = manual
1 = auto
Tap-changer operating (TCO) I2 R 0 = TCO not activated
1 = TCO activated
Outputs
Raise O1 R 0 = signal not active
1 = signal active
Lower O2 R 0 = signal not active
1 = signal active
Raise O11 R,W(P) 0 = signal not active
1 = signal active
Lower O12 R,W(P) 0 = signal not active
1 = signal active
Enable parameters 011...012 O21 R,W(P) 0 = output relays disabled
1 = output relays enabled
Settings used
Present checksum of switchgroup SGF1 S1 R 0…255
Present value of tap-changer position
corresponding to low mA signal S2 R 0…34
Present value of tap-changer position
corresponding to high mA signal S3 R 1…35
Present value of output pulse duration S4 R 0.5…10.0 s
Main settings
Main checksum of switchgroup SGF1 S21 R,W(P) 0…255
Main value of tap-changer position
corresponding to low mA signal S22 R,W(P) 0…34
Main value of tap-changer position
corresponding to high mA signal S23 R,W(P) 1…35
Main value of output pulse duration S24 R,W(P) 0.5…10.0 s
Second settings
Second checksum of switchgroup SGF1 S41 R,W(P) 0…255
Second value of tap-changer position
corresponding to low mA signal S42 R,W(P) 0…34
Second value of tap-changer position
corresponding to high mA signal S43 R,W(P) 1…35
Second value of output pulse duration S44 R,W(P) 0.5…10.0 s
