ABB Terra Gateway Pro User Manual

INSTALLATION MANUAL
STATUS
Released
SECURITY LEVEL
Public
REV.
001
LANG.
en
PAGE
15/31
© Copyright 2022 ABB. All rights reserved.
5
Power button
Power button
6
Power, CFast, Link, Run
LED status indicators
(refer to table Led status for
details)
7
ETH2
Ethernet 2 interface
8
CFast
CFast slot
9
Reset button
Reset button
10
ETH1
Ethernet 1 interface
11
Off/On
Termination resistor
12
L1, L2, L3
LED status indicators
13
IF option
ETH3 & ETH4 – not used
14
Monitor/Panel interface (configuration-
dependent)
Montior/Panel interface
15
Screw point for cable shield
16
Battery compartment on the underside
Battery compartment
3.3.1 Led status (Power, CFast, Link, Run)
LED
Color
Status
Explaination
Power
Green
On
Power supply ok
Red
On
The system is in power saving (standby) mode.
Blinking
The MTCX is running; the battery state is "BAD".
The system is in power saving (standby)
Red-Green
Blinking
Faulty or incomplete BIOS
CFast
Yellow
On
Indicates CFast access
Link
Yellow
On
Indicates an active SDL connection on the panel
connector
Blinking
An active SDL connection was interrupted due to
power loss of the panel
Run
Green
Blinking
Operating system is starting up.
On
Application running
Red
On
Application in service mode
Orange
Blinking
License violation has occurred.
3.4 Network overview
The table below lists the open ports that can be accessed via Terra Gateway Pro ethernet port.
Ports
Description
Function
22/tcp
SSH
Service and maintenance
5353/udp
mDNS
