ABB Terra Gateway Pro User Manual

INSTALLATION MANUAL
STATUS
Released
SECURITY LEVEL
Public
REV.
001
LANG.
en
PAGE
28/31
© Copyright 2022 ABB. All rights reserved.
8 Technical data
8.1 Parts included in delivery
Part
Specification
Terra Gateway Pro
Refer to the type plate in section 3.2
Mounting bracket
Attached to the industrial PC. Refer to section 4.2.6
Mounting plate screws
Torx T20 4 pieces. Refer to section 4.2.6.
Terminal block 0TB103.9
8.2 Required tools for installation
Tool
Specification
Bolts
Size M15 2 pieces
Screwdriver, cross
Size M5
Screwdriver, flat
Size M2.5
Screwdriver, Torx
Type T20
8.3 Required parts for installation
Part
Specification
24 V DC power supply
Power supply for the TGP. Refer to section 0.
Ethernet cable(s)
Connect the TGP to the router/switch.
Refer to section 6.3.
Router / switch
Router/switch for the local network of the site.
Refer to section 4.2.6.
Modem
Internet connectivity of the site.
Refer to section 4.2.6.
8.4 Cable specifications
8.4.1 Power cable
Part
Specification
DC power connection (24V, 0V)
≥1.5mm
2
cross section
Ground connection
≥2.5mm
2
cross section
