ABB TPL67-C Series User Manual

Operation Manual / TPL67-C.. - TPL71-C..
Spare parts
12
Ordering spare parts
12.1
Page 129
© Copyright 2017 ABB. All rights reserved.
February 2017 HZTL2488_EN Revision D
Spare parts
Ordering spare parts
12.1
When making inquiries or ordering spare parts, the following data must be
specified:
 Turbocharger type
 Serial number (HT……)
 Description and part number
Spare parts can be ordered from an official ABB Turbocharging Service
Station.
 If different design versions have not been taken into consideration in
this document, please contact an ABB Turbocharging Service Station.
CAUTION
Storage of spare parts
All spare parts ordered with the turbocharger must be kept complete
and ready for use.
 Parts showing signs of rust should be carefully cleaned and greased.
 Dispose of replaced and unusable parts in a professional and envi-
ronmentally compatible way.
Required customer spare part set (97070)
The customer spare part set (97070) is required for the work described in
this operation manual. These parts are available only as a complete set.
Quantity
Description
Part number
1
O-ring
42012
1 Gasket 42041
2
Gasket
42045
2 Verbus Ripp® washer 42058
2
Hexagon-head screw
42059
3 Hexagon nut 61037
12
Hexagon-head screw
61056
12 Verbus Ripp® washer 61057
3
Verbus Ripp® washer
61058
3 Hexagon-head screw 61059
1
Gasket
77005
1 O-ring (speed sensor) 86506
12
12.1
