Acer Aspire 4250 User Manual

3-42 Machine Maintenance Procedures
LCD Bracket Removal 0
Prerequisite:
LCD Panel Removal
1. Remove the six (6) screws (A) (Figure 3-39).
Figure 3-39. LCD Bracket
2. Remove LCD bracket from the LCD panel.
LCD Bracket Installation 0
1. Put LCD bracket on the LCD panel (Figure 3-39).
2. Install and secure six (6) screws (A) to the LCD bracket (Figure 3-39).
3. Install LCD panel.
ID Size Quantity Screw Type
A M2.0*3.0 6
A
A
A
A
A
A

Acer Aspire 4250 Specifications

General

RAM	2 GB DDR3
Storage	320 GB HDD
Operating System	Windows 7 Home Basic
Battery	6-cell Li-ion
Weight	2.2 kg
Memory	DDR3
Graphics Variant	Integrated
Optical Drive	DVD-Super Multi DL drive
Card Reader	Multi-in-1 card reader
Webcam	Acer Crystal Eye webcam
Networking	802.11b/g/n Wi-Fi, Gigabit Ethernet
Graphics	AMD Radeon HD 6320
Display	14.0 inches
Chipset	AMD A50M
Display Features	LED-backlit
Audio	Built-in speakers and microphone
Ports	3 x USB 2.0, HDMI, VGA, Ethernet (RJ-45)
