Acer Aspire 4349 User Manual

Machine Maintenance Procedures 3-29
CPU Processor Removal 0
Prerequisite:
Thermal Module Removal
1. Find CPU processor (B) on Mainboard. Refer to Figure 3-26.
2. Rotate the cam lock (A) to the unlocked position (Figure 3-25).
Figure 3-25. CPU Processor
3. Remove CPU processor (B) from Mainboard (Figure 3-26).
Figure 3-26. CPU Processor
A
B

Acer Aspire 4349 Specifications

General

Processor	Intel Pentium B940
RAM	DDR3
Storage	320 GB HDD
Display	1366 x 768
Graphics	Intel HD Graphics
Operating System	Windows 7 Home Basic
Battery	6-cell Li-ion
Optical Drive	DVD-Super Multi DL
Dimensions	342 x 245
