Machine Maintenance 3-41
6. Disconnect the DC-input cable from mainboard.
Figure 3-58. DC-input Cable
7. Remove the mainboard from the lower cover.
Figure 3-59. Mainboard
NOTE:
NOTE:
A circuit board that is >10 cm2 has been highlighted with a yellow rectangle in
Figure 3-59. Follow the local regulations for disposing this type of circuit board.
