3-14 Machine Maintenance
4. Lift the HDD from its compartment.
Figure 3-12. HDD Module
5. Remove the two (2) screws securing the HDD bracket.
Figure 3-13. HDD Module
Table 3-5. Screws
Step Screw Quantity Screw Type
HDD Bracket Disassembly M3 x L4 2
