Chapter 5 157
USB/B Board
Power Board
Item Description
JUSB1/JUSB2 USB Connector
ITEM DESCRIPTION ITEM DESCRIPTION
LED1 For NEW75 ON/OFF LED LED9 Not Use
LED2 For NEW85 ON/OFF LED LED10 For NEW75 WLAN LED
LED3 For NEW95 ON/OFF LED LED11 Not Use
LED4 For NEW75 MEDIA LED LED12 For NEW95 WLAN LED
LED5 For NEW85 MEDIA LED SW1 For NEW75 Power BTN
LED6 For NEW95 MEDIA LED SW2 For NEW85 Power BTN
LED7 For NEW75 WWAN LED SW3 For NEW95 Power BTN
To Next Page
