Chapter 3
51
Removing the Logic Lower Door
1.
Remove two (2) screws from the logic lower
door
.
2.
Lift the door beginning from the inner edge as shown.
3.
Lift the door clear of the de
vice, exposing the HDD,
DIMM, and WLAN mo
dules.
Ste
p
Size
Quantity
Screw T
ype
Logic lower door
M2.5*8
2
60
