72
Chapter 3
Removing the Card Reader Board
1.
See “Removing the Upper Cove
r” on page 61.
2.
Unlock the mainboard to card reader cable connector
.
3.
Remove one (1) screw from the
card reader board
.
4.
Lift the card reader board clear of the device.
Ste
p
Size
Quantity
Screw T
ype
Card Reader
M2*3
1
81
83
