Hardware Specifications and Configurations 1-31
LED 15.6”
Item Specification
Vendor/Model name
AUO/B156XW02 V3
Samsung/LTN156AT02-101
LG/LP156WH2-TLF1
LG/LP156WH2-TLFA
AUO/B156XW02 V2 (HW:4A)
Samsung/LTN156AT02-A02
LG/LP156WH2-TLE1
LG/LP156WH2-TLEA
CMO/N156B6-L0B
INNOLUX/BT156GW01 V2
Screen Diagonal (mm) 394.91 mm
Active Area (mm) 344.23 mm x 193.54 mm
Display resolution (pixels) 1366 x 3(RGB) x 768
Pixel Pitch (mm) 0.252mm × 0.252 mm
Typical White Luminance
(cd/m
2
) also called Brightness
220 cd/m
2
Contrast Ratio 400 min / 500 type
Response Time (Optical Rise
Time/Fall Time) msec
8 ms / 16 ms
Typical Power Consumption
(watt)
5.15 W
Weight (without inverter) 460 max
Physical Size (mm) 360 mm x 210mm x 5.5 max
Electrical Interface 1 channel LVDS
Viewing Angle (degree)
Horizontal (Right) CR = 10
(Left)
Vertical (Upper) CR = 10
(Lower)
40 (Right) / 40 (Left) / 10 (Upper) / 30 (Lower) min.
