Hardware Specifications and Configurations 1-37
Card Reader 0
Table 1-39. Card Reader
System LED Indicator 0
Table 1-40. System LED Indicator
System DMA Specification 0
Table 1-41. System DMA Specification
Suspend to RAM (S3) CPU set power down, VGA Suspend, PCMCIA Suspend,
Audio, Power Down, Hard Disk Power Down, CD-ROM Power
Down, Super I/O Low Power mode.
Save to Disk (S4) Also called Hibernation Mode. System saves all system states
and data onto the disc prior to power off the whole system.
Item Specification
Chipset Realtek RTS5138-GR
Package LQFN 48P
Maximum supported size SD: 2T, MMC: 16G, miniSD: 16G, MS:32G, xD:8G
Features Supports SD Extended Capacity (SDXC), compliant with the
SD Memory Card Specification Version 3.0.
Item Specification
Power indicator
Blue color solid on: System on
Blue color and amber color off: System off
Amber color blinking: S3 state
Battery state Charging
Amber solid on - Battery charging with AC
Blue color solid on - Battery full
Amber blinking - Battery abnormal stop charge or battery in
low power state
Discharging
Amber and blinking - Battery in critical low state
Amber color off - Discharging state
Hardware DMA System Function
DMA0 Not applicable
DMA1 Not applicable
DMA2 Not applicable
Item Specification
To Next Page
