Acer V193W Product Service Manual

- 19 -
Texture
Uc: AT-IM-D02;
Bezel: AT-IM-D01
Base: AT-IM-D02

Color
BEZEL : DB27A;
UC: DB27A
Base : DB27A

3.6.4 Carton
Item
Condition
Spec
OK
N.A
Remark
Color
Kraft

Material
B Flute

Compression strength
200KGF

Burst Strength
14 KGF/cm
2

Stacked quantity
5 Layers Vertical

3.7. Pallet & Shipment
3.7.1 Container Specification
Stowing Type
1.1.1.1.1.1.1 C
ontainer
Quantity of products
(sets)
(Every container)
Quantity of Products
(sets)
(Every Pallet)
Quantity of pallet
(sets)
(Every Container)
With pallet
20'
900
Pallet A: 90
Pallet A: 10
Pallet B:
Pallet B:
40'
1980
Pallet A: 90
Pallet A: 22
Pallet B:
Pallet B:
Without pallet
20'
X
X
X
X
40'
X
X
X
X
3.7.2 Carton Specification
3.7.2.1 Product:
Net Weight (Kg)
Gross Weight (Kg)
Dimension w/o Base
W*H*D (mm)
Dimension w/ Base
W*H*D (mm)
4.3Kg
5.3Kg
440.24*292.15*65 mm
440.24*357.73*161.14mm
3.7.2.2 Package:
Carton Interior Dimension (mm)
L*W*H
Carton External Dimension (mm)
L*W*H
498*114*400mm
506*126*415 mm

Acer V193W Specifications

General

Pixel pitch	0.284 x 0.284 mm
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Vertical scan range	55 - 75 Hz
Viewable size, vertical	255 mm
Contrast ratio (typical)	2000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	408 mm
Viewing angle, horizontal	176 °
Display brightness (typical)	300 cd/m²
Certification	UL, CUL, TUV/GS, T-Mark, ISO9241-3/-7/-8, FCC/B, VCCI, CE, TCO03, C-tick, BSMI, WHQL, ISO 13402-6
Product color	Black
Market positioning	-
Cable lock slot	Yes
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (off)	1 W
Power consumption (standby)	2 W
Power consumption (typical)	26 W

Weight and Dimensions

Depth (without stand)	360 mm
Width (without stand)	442 mm
Height (without stand)	162 mm
Weight (without stand)	4300 g
