Acer V193W Product Service Manual

- 65 -
Appendix 1 – Screw List / Torque
(A)
STANDARD SCREW TORQUE SPEC.
ITEM
P/N
DESCRIPTION
MOUNTING
MATERIAL
TORQUE
(KG-CM)
HOLE SIZE
(MM)
Screw
Head
1
8F.205B4.019
SCRW MACH HEX #4-40*0.3" NI
METAL
5.0±0.6
#4-40
X
2
8F.5A224.5R0
SCRW MACH FLAT M3*5L ZN
METAL
Side mount:3±0.6
Other: 4±0.6
M3*0.5
#2
3
8F.XA356.6R0
SCRW TAP FLAT M4*6L B-ZN NYL
METAL
9.0±1.0
M4*0.7
#2
4
8F.8A356.100
SCREW MACH FPH M4*10L B-ZN
NYL
METAL
11.0±1.0
M4*0.7
#2
5
8F.5A356.8R0
SCRW MACH FH M4*8L B-ZN NYL
METAL
9.0±1.0
M4*0.7
#2
6
6K.L7204.001
ASSY SCREW M4*10L FP527
METAL
11.0±1.0
M4*0.7
#2
7
6K.L8810.001
ASSY SCREW M4*8L FP726A NLK
ISU
METAL
9.0±1.0
M4*0.7
#2
9
6K.L8811.001
ASSY SCREW M4*6 FP726A NLK
ISU
(8F.5A456.6R0+4B.L7212.001)
METAL
9.0±1.0
M4*0.7
#2
10
8F.5A422.2R4
SCRW MACH FLAT-P M2*2.4L ZN
Plastic
1.0±0.1
1.4±0.05
#1
11
8F.VA512.4R0
SCRW TAP PH M2*4L NI
Plastic
1.0±0.2
1.6±0.05
#1
12
8F.XA213.8R0
SCRW TAP FLAT/PT M2.5*8L ZN
Plastic
4.0±0.5
2.0±0.05
#1
13
8F.WA314.8R0
SCRW TAP CAP M3*1.34P*8L B-ZN
PLASTIC
5.0±1.0
2.35±0.05
#2
14
8F.XA524.6R0
SCRW TAP FLT M3*6L NI
PLASTIC
4.5±0.5
2.35±0.05
#2
15
8F.XA314.8R0
SCRW TAP FLAT M3*1.34P*8L B-ZN
PLASTIC
4.5±0.5
2.35±0.05
#2
16
8F.XA326.100
SCRW TAP FLAT M4*10L B-ZN
Plastic
7.5±0.5
3.4±0.05
#2
17
8F.MA224.5R5
SCRW TAP FLAT-P M3*5.5L ZN
Metal
None tread
：
8
～
10
Have tread:6
～
8
Aluminum:4~5
2.68±0.03
#2
18
8F.MA324.5R5
SCRW TAP FLAT-P M3*5.5L B-ZN
Metal
None tread
：
8
～
10
Have tread:
5.0±1.0
Aluminum:4~5
2.68±0.03
#2
19
8F.00273.6R0
SCRW TAP PH F/10WSH M3*6L C-
ZN
Metal
None tread
：
8
～
10
Have tread:6
～
8
Aluminum:4~5
2.68±0.03
#2
20
8F.VZ526.6R0
SCRW TAP FLAT+EXTM4*6L ZN-W
Metal
10±1.0
M4*0.7
#2
21
8F.00007.144
SCREW TAP CAP #4-40*10 ZN
Aluminum
3.3±0.3
2.6±0.03
#2

Acer V193W Specifications

General

Pixel pitch	0.284 x 0.284 mm
Display diagonal	19 \
Display resolution	1440 x 900 pixels
Vertical scan range	55 - 75 Hz
Viewable size, vertical	255 mm
Contrast ratio (typical)	2000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	408 mm
Viewing angle, horizontal	176 °
Display brightness (typical)	300 cd/m²
Certification	UL, CUL, TUV/GS, T-Mark, ISO9241-3/-7/-8, FCC/B, VCCI, CE, TCO03, C-tick, BSMI, WHQL, ISO 13402-6
Product color	Black
Market positioning	-
Cable lock slot	Yes
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (off)	1 W
Power consumption (standby)	2 W
Power consumption (typical)	26 W

Weight and Dimensions

Depth (without stand)	360 mm
Width (without stand)	442 mm
Height (without stand)	162 mm
Weight (without stand)	4300 g
