24 User’s Guide
13 Wireless Communication Feature
The system supports Wireless Communication via an onboard infrared
interface (CN2 - see Figure 2). This feature enables the system to
communicate with SIR (Serial InfraRed)-aware peripherals without the
aid of cables.
The onboard infrared interface is IrDA-compliant, allowing data
transfer at a rate of 115.2 kilobits per second (Kbps) at a maximum
distance of one meter.
14 Hardware Monitoring Function
The Hardware Monitoring function allows you to check the system
resources, either locally or in a computer network, by using software
such as Intel LDCM (LAN Desk Client Manager). ADM and Intel
LDCM are desktop management programs that offer the SMART
(System Monitoring Analysis and Reporting Technology) monitor
function for checking local or network connected systems. In addition,
it also enables the PC products and applications to be OS (operating
system) independent.
To enable the Hardware Monitoring function, you need to install Intel
LDCM. Contact your dealer for information on the availability of the
software. Refer to the software documentation for more details on the
Hardware Monitoring function.
15 Wake-on Ring-in Function
The Wake-on Ring-in function enables the system to resume from
suspend mode by monitoring the fax/modem (or any device of similar
type) activities. Any signal or activity detected from the Modem ring-in
connector automatically returns the system to normal operation. Refer
to Figure 2 for the location of the Modem ring-in connector (CN9) on
the system board.
