3.3 Onboard Connector Functions
Table 2 lists the onboard connectors and their respective functions.
Table 2 System Board Connectors
Connector Function
CN1 USB port
CN2 Power LED (pins 1-3)
HDD LED (pins 4-7)
Reset button (pins 8-9)
Power button (pins 10, 20)
IrDA connector (pins 14-19)
Turbo LED (pins 11-13)
CN3
Upper:
PS/2 mouse port
Lower:
PS/2 keyboard port
CN4 ATX power connector
CN5 ATI AMC feature connector
CN6
Upper:
Parallel port
Lower:
VGA port (right)
COM2 port (left)
CN7 Wake-on LAN connector
CN8 COM1 port
CN9 Modem ring-in connector
CN10 IDE2 connector
CN11 IDE1 connector
CN12 Floppy disk drive connector
CN13
Upper:
Game/MIDI port
Lower:
(R-to-L)
Microphone-in port
Stereo line-in port
Stereo line-out port
CN14 Fax/voice connector
CN15 CD-in connector
CN16 Volume control connector
CN17 External CS4610 connector
FN1 2-pin CPU fan connector
FN2 5-pin CPU fan connector
